Specifications

• Capacity: 20000
• Working fluid pressure - 125-250kg/cm2
• Piston stroke, max - 700mm
• Piston travel speed:
  • - idle travel - 0.05-0.3mm/sec
  • - reverse travel - 6mm/sec;
• Max distance between table and press ram - 1900mm
• Moving table size - 1940mm x 3900mm
• Press dimensions:
  • - length - 5600mm
  • - width - 6000mm
• - height above floor level - 6125mm
• - total height - 11635mm
• Press weight - 1,090t
