Forging Machinery

1,600 Ton Erie mechanical hot forging press built in 1980 t

Specifications

Capacity	1600 tons @ 1/8" up
Stroke - Ram	12"
Main Shaft Diameter At Journals	18"
Main Shaft Diameter At Eccentric	28-1/4"
Width of Eccentric Bearing
Shut Height With Top Knockout Plate	34-1/2"
Shut Height With Top Knockout Plate in Place	30"

NOTE: Shut Height Is With Wedge Adjusted 1/4" Up/Stroke Down

Strokes Per minute (Continuous)	65
Distance Between Columns	39-3/8" R-L; 30" F-B
Die Seat R-L x F-B	39-3/8" x 43"
Ram Face R-L x F-B	38" x 38"
Lower Knockout Stroke	5/8"
Upper Knockout Stroke	3/4"
Floor Space R-L x F-B	l0' 6" x 10" 6-1/4"
Height Above Floor	15' 3-1/2"
Distance Below Floor	36-7/8"
Standard Motor Horsepower	100
Approximate Net Weight	188,000 Lbs.

Request a Quote

4,000 Ton Weingarten model PZS 630 Screw Press

Specifications

Main Data of Machine PZS 630, Order 152 041

Specifications	Inches	MM
Striking Force
-normal	4,400 US-T	4,000 mp
-impact, approx.	8,800 US-t	8000 Mp
-max. perm. Continuous force	7,000 US-t	6,400 Mp
Gross Potential energy	732,000 Ft-lbs	1000,000 mkp
Nominal pressure approx.	542,000 Ft-lbs	75,000 mkp
Anchor preload	9,900 US-T	9,000 Mp
Theoretical number of Strokes	14-18 /min
Utilizable number of strokes	10/min.
Spindle dia., min,	24.9	630
Max. stroke	29.5	750
Min. stroke	11.0	280
Stroke for obtaining max. capacity	29.5	750
Time for ram downward movement at 750 mm stroke approx..	2.1 sec
Impact speed approx.	23”/sec	0.6 m/sec
Distance between table and ram stroke down	47.2	1,200
Stroke up	76.8	1,950
Width between uprights below guide ways	65.0	1,650
In-between guide ways	45.3	1,150
Table clamping surface width x depth	63.0 x 55.0	1,600 x1,400
Ram clamping surface	51.5 x 55.0	1,300 x1,400
Power requirements approx..		860 K
Input of flywheel drive motors together approx..		2,800 Ampere
Idling speed of motor		600 rpm
Machine height above floor approx.	27’	8,200
Net weight of complete machine approx..	341 US-T	310 t
Number of preselect able strokes	3
Total spring number C of Press, min.	24,000 US-t/”	850 Mp/mm

Request a Quote

4,000 Ton National MP Mechanical Hot Forging Press

Hot Forging Press

Specifications

The following specifications are for the original machine including any known changes.

Discrepancies may exist between specifications and the current machine.


Machine Size	4000 MP
Shipped from Tiffin OH	2/11/1972
Strokes per minute	46
Stroke	15"
Shut Height	39"
Brake style	Band
Electrical Specs	460V, 3Ph.

Machine is disassembled and ready for shipment.

Request a Quote

Brand New! 12,500 Ton China Heavy Machinery Mechanical Hot Forging Press

Forging Press

Specifications

Table size 2240x3100mm
Slide size 2190x2450mm
Slide stroke 520mm
Die height 1800mm
Speed 30SPM

Brand new 12500t forging press has been fully tested and dismantled. It is a closed die forging press. Request a quote today!

Request a Quote

1,500 TON WATSON STILLMAN HYDRAULIC PRESS

Specifications

4-post hydraulic forging press built in 1951
55” stroke, and a 115” maximum daylight opening and a 78” x 72” bed/die area
The year it was operational at the plant was 1951
This has been used as a forging press and a straightening press

Request a Quote

16,000 Ton SMS MEER/EUMUCO mechanical forging press

16,000 Ton SMS MEER/EUMUCO

mechanical forging press

Specifications

Maker: SMS Meer Germany

This line includes:

16,000 Forging press
6000 kw induction heater
Rolling press
1600 Ton trimming press
Twister press
2000 Ton straighten press
8 sets of Kuka Robert for handling 500kg

Design output: 310000 PCS a year of front axle and or crankshafts Cycle time: 50 sec. per piece Fully automatic operation integrated by SMS Meer Total weight: 1750 ton Purchased cost for the press alone was 20 Million Euros Current condition: Boxed and Stored in China.

Request a Quote

5,000 lbs. Chambersburg Ceco Forging Hammer

Specifications

5,000 lbs. Chambersburg Ceco Forging Hammer

Request a Quote

FICEP Model PVM-360 Screw Press

1984

Currently dismantled and warehoused in Vera Cruz, Mexico.

Specifications

Screw Diameter: 360mm
Nominal Force: 13,000kN
Max Allowed Force Continues Operation: 26,000kN
Max Gross Energy: 205,000Nm
Ram Stroke: 550mm
Strokes Per Minute: 18-20
Height from Bed to Ram(ram at bottom): 900mm
Inside distance between columns: 900mm
Bed Depth: 1,250mm
Bed Width: 900mm
Main Motor Power: 45/75kW
Approx. Weight: 80,000kg

Request a Quote

30000 ton UZTM Hydraulic Forging Press

Built in Russia

Specifications (Russian Language)

Specifications

Vertical, 4 columns with low position of working cylinders, with movable traverse and table,
Main Drive type - from pumping-accumulating station with pressure up to 320 kgs/cm2
stroke - 3500 mm
bed area - 2500 x 3000 mm

Request a Quote

1,600 Ton Smeral Hot Mechanical Forging Press

Built in Czech Republic

The press itself has the latest rigid Shmeral design the following design features:

press frame is one-piece monoblock castings
both parts of the press frame are connected by four tie rods made from forged bars
the eccentric shaft is located from the front to the back of the press
the shut height adjustment is located in the ram; it is manual
the ram has extra-long guides allowing for increased product quality
the flywheel of the press has the mechanical overload protection with friction liners and Bellville springs.

Specifications

Nominal force	1,600 metric tons
Slide stroke	280mm
Number of continuous strokes per min	85
Maximum numer of single strokes per min	35
Shut height - slide down, adjustment up	760mm
Shut height adjustment	10mm
Table dimensions LR x FB	1,180mm x 1,120mm
Slide dimensions LR x FB	1,000mm x 920mm
Maximum stroke of lower ejector	60mm
Maximum stroke of upper ejector	45mm
Main motor power	75kWt
Press total weight	85,000kg

Request a Quote
